High Temp PRO Resin

High Temp Resin combines the detail precision of MSLA technology with the ability to maintain dimensional properties in conditions of temperatures of up to 190°C. Therefore, it lends itself well to both the creation of functional prototypes and end parts, such as moulds or connectors.

Instant Quote Gallery

Offers the highest thermal distortion temperature for resins achievable with MSLA technology
Excellent surface performance and precision of detail.
Possibility to make moulds directly for casting or injection for small series

This high temperature resin offers high dimensional stability, a smooth surface finish and high mechanical strength for moulding applications.

With a heat deflection temperature of 238°C, this resin is designed to withstand high process temperatures and is the perfect choice for many applications where high temperature resistance is critical.
From prototyping and production to moulding, this resin will help you create professional-quality designs.

Processing:
- 3D MSLA Stereolithography
Alternative nomenclature:
- High Temperature PRO Resin
Price range: € € € € €
Ideal for:
- Functional Parts
- High temperature applications
- Molds
- Castings
- Connectors

"Precision of detail at high temperatures"

For parts that require the high-quality finish of resin and must be used in contact with hot fluids up to 190°C or in thermally demanding work environments, such as moulds, inserts, connectors, housings or fixings.

Simone, Technical Engineer Weerg

Main features

Offers the highest thermal distortion temperature for resins achievable with MSLA technology
Excellent surface performance and precision of detail.
Possibility to make moulds directly for casting or injection for small series

Properties

Tensile breaking load 75 MPa
Modulus of elasticity 3192 MPa
Elongation at break 3 %
Flexural modulus 3168 MPa
HDT 0.45 MPa 238 °C
Izod impact resistance 14.6 kJ/m2

Features

Price range € € € € €
Lead time <2 days
Maximum dimensions
274 x 155 x 400 mm

10.8 x 6.1 x 15.7 in
Minimum wall thickness 1 mm
Tolerance
< 100mm ± 0,30mm

> 100mm ± 0,3%
Layer height 50 µm

Data sheet

Gallery

Application Sectors

Production technologies

Mask Stereolithography

Learn more about technology

Masked Stereolithography (MSLA) is a 3D printing or additive manufacturing process that uses UV-sensitive liquid resins as a material. These UV rays are used to impress a selected area (through a mask) of the print area that will then solidify. Level after level, the desired object will be created, from the bottom up. The ...
